Current numerical algorithms for simulating friction fall in one of two camps: smooth solvers sacrifice the stable treatment of static friction in exchange for fast convergence, and non-smooth solvers accurately compute friction at convergence rates that are often prohibitive for large graphics applications. We introduce a novel bridge between these two ideas that computes static and dynamic friction stably and efficiently. Our key idea is to convert the highly constrained non-smooth problem into an unconstrained smooth problem using logarithmic barriers that converges to the exact solution as accuracy increases. We phrase the problem as an interior point primal-dual problem that can be solved efficiently with Newton iteration. We observe quadratic convergence despite the non-smooth nature of the original problem, and our method is well-suited for large systems of tightly packed objects with many contact points. We demonstrate the efficacy of our method with stable piles of grains and stacks of objects, complex granular flows, and robust interlocking assemblies of rigid bodies.

We present a rigid body animation technique which prevents solids from interpenetrating, dissipates energy through friction, and propagates shocks through contacts. We employ the Alternating Direction Method of Multipliers (ADMM) to couple non-smooth Coulomb friction with impact propagation, allowing efficient and accurate non-smooth dynamics along with a correct transmission of impacts through assemblies of rigid bodies. We further extend our method to model adhesion, dynamic friction and lubricated contact.

We introduce a compact, intuitive procedural graph representation for cellular metamaterials, which are small-scale, tileable structures that can be architected to exhibit many useful material properties. Because the structures’ “architectures” vary widely—with elements such as beams, thin shells, and solid bulks—it is difficult to explore them using existing representations. Generic approaches like voxel grids are versatile, but it is cumbersome to represent and edit individual structures; architecture-specific approaches address these issues, but are incompatible with one another. By contrast, our procedural graph succinctly represents the construction process for any structure using a simple skeleton annotated with spatially varying thickness. To express the highly constrained triply periodic minimal surfaces (TPMS) in this manner, we present the first fully automated version of the conjugate surface construction method, which allows novices to create complex TPMS from intuitive input. We demonstrate our representation’s expressiveness, accuracy, and compactness by constructing a wide range of established structures and hundreds of novel structures with diverse architectures and material properties. We also conduct a user study to verify our representation’s ease-of-use and ability to expand engineers’ capacity for exploration.

Simulating liquid phenomena utilizing Eulerian frameworks is challenging, since highly energetic flows often induce severe topological changes, creating thin and complex liquid surfaces. Thus, capturing structures that are small relative to the grid size become intractable, since continually increasing the resolution will scale sub-optimally due to the pressure projection step. Previous methods successfully relied on using higher resolution grids for tracking the liquid surface implicitly; however this technique comes with drawbacks. The mismatch of pressure samples and surface degrees of freedom will cause artifacts such as hanging blobs and permanent kinks at the liquid-air interface. In this paper, we propose an extended cut-cell method for handling liquid structures that are smaller than a grid cell. At the core of our method is a novel iso-surface Poisson Solver, which converges with second-order accuracy for pressure values while maintaining attractive discretization properties such as symmetric positive definiteness. Additionally, we extend the iso-surface assumption to be also compatible with surface tension forces. Our results show that the proposed method provides a novel framework for handling arbitrarily small splashes that can also correctly interact with objects embodied by complex geometries.
